Features
Intelligent digital design
Strong dual core microprocessors with embedded operating system
High accuracy inspection :0.05mm
High efficiency testing, can cooperate to automated machinery test
Skilled manufacture and easy to carry
One-page menu, real-time on-screen instructions, can be realized fool-type operation
Main Technical Data | |
Frequency range | 10Hz-10MHz |
Independent frequency detection No. | 2 |
Phase | 0-359°,continuously adjustable, precision 1 ° |
Gain | 0 dB ~ 99 dB, a wide gain adjustment 0.5dB |
Display | colorful 5.7"，TFT LCD |
Digital Filtering | High-pass frequency (0Hz ~ 2000Hz), low-pass frequency (0Hz ~ 2000Hz) |
Alarm mode | Multi-mode、non-constant-amplitude phase / amplitude domain Alarm、built in alarm |
Data storage | Testing Parameters , Testing Results, Query, Playback file |
Built-in rechargeable of lithium battery | 10hour |
Operating System | LINUX |
Operating Language | Chinese , English |
